Kinetic Matrix strobe bar——Ideal for a wide range of large-scale events: commercial spaces, TV shows, concerts, nightclubs, and various other settings
The FENG-YI Kinetic Matrix Strobe Bar delivers dynamic lighting for large-scale events. Perfect for concerts, TV shows, nightclubs, and commercial spaces, it enhances visual impact with vibrant, synchronized strobes. Elevate your event’s atmosphere with this versatile lighting solution.
◉ Product Features
Dual Winch Lifting, Heavy-Duty Stability
Twin winches work simultaneously, supporting up to 40kg for stable lifting of large fixtures.
Dual Lighting System, Beam & Wash Combined
20×40W RGBW beams and 480 RGB strobes offer both intense spot lighting and full-area washing.
Intelligent Control, Multi-Channel Operation
DMX512/RDM protocol support with independent channel assignment for precise and flexible control.
Integrated Safety Design, Easy Installation
Pre-assembled system includes safety hanging accessories, enabling quick setup from 6 meters.
◉ Specifications
| Item No. | DLB-H3-11067 (3 meters) | ||
| DLB-H6-11068 (6 meters) | |||
| Fixture | 20 Pixels | ||
| 20 pcs 40W RGBW 4 in 1 LED | |||
| Beam angle: 1.5° | |||
| Power: 180W | |||
| Beam diameter: D63mm | |||
| Material: Aluminium+PE+PCB | |||
| Power: 900W | |||
| Weight:6.5kg | |||
| Dimensions : L 1025xW150xH200 mm | |||
| Winch（0-6m） | Lifting height: 0-6meters | ||
| Average lifting speed: 0.3m/s(3meters)；0.46m/s(6meters) | |||
| Material: Aluminium | |||
| Housing color: Black | |||
| Power: 160W(1pcs) | |||
| Dimensions : L342 *W280*H432mm | |||
| Weight: 16.5kg(1pcs) | |||
| IP Class 20 | |||
| Group | Winches x 2 | ||
| Strobe Bar x 1 | |||
| Control | Graphic LCD control panel | ||
| 4 Menu buttons to set the functions | |||
| DMX512/RDM Protocol | |||
| DMX channels: Winch A: 152CH Winch B: 4CH | |||
| Electrical and Connectionsz |
AC100 to 240 Volts; 50/60 Hz | ||
| Total power: 1300W Maximum | |||
| Total weight: 40kg Maximum | |||
| Total weight: 51.5kg Maximum | |||
| 3-Pin XLR input and output | |||
| PowerCON input and output, Maximum connect 4 winches via daisy chain（220V）;Maximum connect 2 winches via daisy chain(110V) | |||
| Ambient temperature:5-40° | |||
| Installation | The minimum installation height is6 meters | ||
| Ensure vertical hang | |||
| 4 x FY-SE-70002 clamps for hanging installation | |||
| Safety wire attachment hole | |||
◉ Applications
Nightclubs & Bars
Creates dynamic, color-changing circular backdrops and visual accents for dance floors and stages.
Concerts & Music Festivals
Delivers synchronized circular lighting effects that complement live performances and stage productions.
Large - Scale Events
Enhances visual appeal at corporate events, Enhances visual appeal at corporate events, award ceremonies, and themed parties with immersive LED displays.award ceremonies, and themed parties with immersive LED displays.
Theatrical Productions
Adds atmospheric circular lighting and geometric visual elements to theatrical shows and installations.
◉ Advantages
High Pixel Density
40 pixels with 240 RGB LEDs provide fine-grained control over color and pattern, enabling complex circular visual designs.
Robust Aluminium Construction
Ensures structural integrity and durability for repeated use in event environments.
Flexible DMX Control
Multi-channel winch control allows precise adjustment of both lighting effects and physical positioning, offering creative versatility.
Scalable System
Integrates seamlessly with 3×DLB-P12-9108 units for large-scale, coordinated visual experiences with a total power of 400W.
◉ Customization Options
Pixel & LED Configuration
Adjustments to the number of pixels or LEDs for tailored brightness and resolution requirements.
Size & Shape Modifications
Custom dimensions or alternative circular diameters (subject to structural feasibility).
DMX Channel Optimization
Custom DMX channel allocations to match specific control system setups.
Material Upgrades
Options for enhanced aluminium grades or surface finishes for specialized aesthetic or durability needs.
◉ Packaging & Logistic
Packaging
Each unit is packaged in a sturdy carton with foam insulation to protect aluminium components during transit. Custom flight cases are available for bulk orders to ensure safety for multiple units.
Logistics
Shipped via freight or courier services. The product is classified as electronic equipment; ensure transport within the ambient temperature range (5 - 40°C) to avoid damage.
◉ Frequently Asked Questions
Wedding & Parties Lighting Solutions
Is the control system compatible with existing consoles?
Supports DMX / Art-Net / sACN for seamless integration with mainstream consoles; also enables Timecode-driven operation and multimedia synchronized control.
Nightclub Lighting
Can the lighting, screens, and other equipment be combined to achieve integrated sound, lighting, and visuals?
Programming is possible through Madrix and MA consoles, using timecode synchronization to achieve a precise "programmed show" effect.
Will the equipment break down easily? How long is the after-sales service?
Our products are designed specifically for the entertainment industry. They feature excellent heat dissipation and can withstand the harsh, high-temperature, high-humidity, and dusty environments of bars. They are guaranteed to operate continuously for 2,000 hours. We offer a one-year warranty starting from the date of delivery (excluding consumables such as bulbs and LEDs). If the product is damaged due to quality issues, the seller will provide a replacement free of charge.
Customization/OEM Services
What is the production cycle for customized products? Is sample trial production supported?
The production cycle for regular customization (e.g., appearance logo, parameter fine-tuning) is 15-20 days, and the cycle for complex function customization (e.g., development of a new elevating structure) is 30-45 days. Sample trial production is supported. The sample fee is charged based on the customization cost (the fee can be deducted from the payment after bulk ordering). The trial production cycle is 7-10 days, and bulk production will start only after the customer confirms the sample is qualified.
Logistics Services
What logistics method is used by default for products? What is the delivery time for different regions in China?
Dedicated line logistics (e.g., Anneng, Best Express) is used by default. Express delivery (e.g., SF Express, JD Express) or full-truck transportation can also be arranged according to customer needs. Delivery time:
▪ East China/South China/Central China: 3-5 days.
▪ North China/Southwest China: 5-7 days.
▪ Northeast China/Northwest China: 7-10 days.
▪ Remote areas (e.g., Xinjiang, Tibet): 10-15 days, with an additional remote area freight charge (calculated by weight, specific details to be confirmed with the logistics department).
