X激光频闪 - FENG-YI

Lifting X-ray Strobe Light

The FENG-YI Lifting X-ray Strobe Light combines advanced kinetic light fixtures with vibrant color kinetic light technology, delivering dynamic illumination for industrial and artistic applications. Engineered for precision and durability, it enhances visibility and aesthetic impact in any setting.

Specifications

Item No. DLB-CH5-11227

Fixture
1. Flashing Section
32 RGB+ 32 W pixels
576 LEDS,0.2WRGB, 3-in-1 LED
768 pcs,0.5W,5730 Co0l White(11388K)
CalerDcminanWzelergftes
(R)630.4 nm
(G)520.9 mm
(B)457.7 nm
3-meteriluminanee
(R)35.5 luz
(G) 122.5 lux
(B) 22.5 lux
(RGB) 174.9 lux
(W) 1262 lux
2. Oscillating Laser Section
Light Source: 2W(RGB) Laser Light x4 units
Light Source Power: 0.5W (R): 0.35W (G); 1 2W (B)
Y-axis x 4 units
Mbin Color Wfave
(R)638 nm(G)523 nm(B) 448.9 nm
Y-axis x 4 units
Y-axis angle: 0-265°
Maximum Y-axis speed: 0.45 sec /265°
4 head indhspandanyconhrcled
3.Meter spot Diameter: (R/G/B/W) 2.5 cmOthers
Dimensions:L1229xW1229 xH139 mm
Materiat Alloy + PE + PCB
Appearance: Black
Power: 533.4 W
Weight: 8.2 kg
Winch(0-5meters)   Lifting height: 0-5meters
Average lifting speed:0- 0.26m/s
Power: 160W(1pcs)
Dimerdiord:lengh345"Wdh 223*Helgh500 mm
Weight: 18.5kg(1pcs)
Material: Aluminium
Housing color: Black
IP Class:lP20
Group Winches x 3
Matrix Flash x 1
Control Graphic LCD control panel
Four menu button settings funetion
Control Method:DMX512/RDM Control Protocol
Channel Mode:
Main Unit Ae 160 channels
Host B: 4 channeks
Mbin urit C: 4channels
Electrical and  Connectionsz
AC100 to 240 Volts , 50/60 Hz
3-pin + 5-pin xLR input/output signal jack
Blue-white plug input/output power socket, maximum 3hostsin series (220V); maximum 3 hosts in series (1 10V)
Ambient temperature:5-40'
Installation The minimum installation height is 3 meters
Ensure vertical hang
6x FY-SE-70002 clamps for hanging installation
Fixed safety cords

Packaging & Logistic

Packaging - FENG-YI

Packaging

Each unit is packaged in a sturdy carton with foam insulation to protect aluminium components during transit. Custom flight cases are available for bulk orders to ensure safety for multiple units.

Logistics - FENG-YI

Logistics

Shipped via freight or courier services. The product is classified as electronic equipment; ensure transport within the ambient temperature range (5 - 40°C) to avoid damage.

Frequently Asked Questions

Customization/OEM Services
What is the production cycle for customized products? Is sample trial production supported?

The production cycle for regular customization (e.g., appearance logo, parameter fine-tuning) is 15-20 days, and the cycle for complex function customization (e.g., development of a new elevating structure) is 30-45 days. Sample trial production is supported. The sample fee is charged based on the customization cost (the fee can be deducted from the payment after bulk ordering). The trial production cycle is 7-10 days, and bulk production will start only after the customer confirms the sample is qualified.

Products
The lamp does not light up. What should I check?

Troubleshoot in 4 steps:

1. Power Supply: Confirm the input voltage matches AC 200V~240V/50~60Hz; check if the power cable is securely connected and the switch is on.

2. Cooling Period: Ensure the fixture has cooled for 20 minutes after previous use (mandatory cooling to prevent overheat damage).

3. DMX Signal: If in DMX mode, verify the controller is sending "Shutter On" (CH6: 252-255) and "Dimming" (CH7: 100-255) signals.

4. Internal Wiring: If above checks pass, contact after-sales to inspect internal connections (e.g., lamp holder, driver board) for loose or burned components.

The cutting blades do not move linearly. How to troubleshoot?

Fix with these steps:

1. Channel Check: Ensure the correct cutting channel (e.g., Cut 1: CH24) is selected on the controller; set the channel value to 100-255 (0=no movement).

2. Motor Calibration: Enter "Factory Settings → Motor Calibration → Cut 1" and adjust the offset (-128~+127) to compensate for mechanical errors.

3. Mechanical Blockage: Power off the fixture and check if debris (dust, wire) is blocking the blade’s travel path; clean the path with a soft brush and re-test.

Logistics Services
How is the lamp packaging protected? What if damage occurs during transportation?

The packaging adopts three-layer protection: shockproof foam + hard carton + wooden box (for large equipment such as elevating lights). Key parts of the lamp (e.g., moving head light lens, elevating structure) are individually wrapped with EPE foam. If damage occurs during transportation, the customer must take photos (of the damaged packaging and the faulty part of the product) and send them to the logistics department within 24 hours of receipt. We will give priority to reissuing new products (or arranging repairs) and hold the logistics company responsible. The customer does not need to bear additional costs.

Can on-site installation services be provided? How is the installation fee calculated?

On-site installation services are supported, and the fee is calculated based on the installation difficulty and region:

▪ Regular installation (e.g., bar PAR lights, front lights in small studios): 50-100 RMB/unit in prefecture-level cities and above, 80-150 RMB/unit in county-level regions.

▪ Large-scale installation (e.g., elevating lights in stadiums, moving head light groups for music festivals): Quoted based on the overall project (including travel expenses of installers and tool usage fees). Specific details require providing the installation site floor plan and the number of lights, and the engineering team will formulate a plan before quoting.
