Kinetic Crystal pillar——Ideal for a wide range of large-scale events: commercial spaces, TV shows, concerts, nightclubs, and various other settings.
◉ Specifications
| Item No | DLB-Q2-11079 | ||
| Fixture |
2 Pixels | ||
| RGB 3 in 1 + warm white | |||
| Light angle: 360°, beam 3 ° | |||
| Material: Acrylic | |||
| Power: 15W | |||
| Size: D60*H320mm | |||
| Weight: 0.6kg | |||
| Winch(0-2meters) | Lifting height: 0-2meters | ||
| Average lifting speed:0- 0.6m/s | |||
| Power: 60W(1pcs) | |||
| Size: L170 *W170*H205mm | |||
| Weight: 2.9kg(1pcs) | |||
| Material: Aluminium | |||
| Housing color: white | |||
| IP Class:lP20 | |||
| Group | Winches x 3 | ||
| Crystal light x 1 | |||
| Control | Graphic LCD control panel | ||
| 4 Menu buttons to set the functions | |||
| DMX512/RDM Protocol | |||
| DMX channels: winch A: 10CH | |||
| Electrical and Connectionsz |
AC100 to 240 Volts , 50/60 Hz | ||
| Total power:70W Maximum | |||
| Total weight: 3.5kg Maximum | |||
| Signal: 0.35m T-type quick docking | |||
| PPower: 0.35m T-type quick docking | |||
| Ambient temperature:5-40' | |||
| Installation |
Ceiling Opening Diameter:D200mm Maximum | ||
| Ceiling clearance: D313mm Miniximum | |||
| Ensure vertical hang | |||
| Embedded installation | |||
| Safety wire attachment hole | |||
| Compliance | CE/Rosh | ||
◉ Product Details
◉ Packaging & Logistic
Packaging
Each unit is packaged in a sturdy carton with foam insulation to protect aluminium components during transit. Custom flight cases are available for bulk orders to ensure safety for multiple units.
Logistics
Shipped via freight or courier services. The product is classified as electronic equipment; ensure transport within the ambient temperature range (5 - 40°C) to avoid damage.
◉ Frequently Asked Questions
Wholesale Cooperation
Are samples provided for wholesale cooperation? How is the sample fee settled?
1-2 standard samples are provided free of charge (the customer needs to bear the freight). For customized samples, a cost fee is charged (e.g., 200-500 RMB/unit for appearance-customized samples). If the customer places a subsequent bulk order (meeting the MOQ of the corresponding product), the sample fee can be fully deducted from the payment, and free samples do not need to be returned.
What is the restocking cycle for wholesale customers? Can production be prioritized?
The restocking cycle for standard models is 3-7 days (same-day shipment if stock is sufficient), and the restocking cycle for customized models is the same as the initial customization cycle (15-45 days). For annual cooperative customers (with an annual purchase amount of ≥ 500,000 RMB), a "priority restocking agreement" can be signed, and 10%-15% of safety stock will be reserved to ensure emergency restocking needs are met within 3 days.
Nightclub Lighting
Can the lighting, screens, and other equipment be combined to achieve integrated sound, lighting, and visuals?
Programming is possible through Madrix and MA consoles, using timecode synchronization to achieve a precise "programmed show" effect.
Customization/OEM Services
Do customized products enjoy the same warranty service as standard products?
Yes, customized products have the same warranty policy as standard products (under non-human damage, the whole machine is warranted for 1 year, and LED lamp beads are warranted for 2 years). For faults caused by customized functions (e.g., adaptation issues of the special light control protocol specified by the customer), the after-sales team will give priority to targeted troubleshooting to ensure no impact on use.
What customization services can you provide? For example, adjustments to appearance, functions, or parameters.
Multi-dimensional customization is supported:
▪ Appearance customization: Lamp housing colors (e.g., in addition to black and silver, exclusive brand colors can be customized), and laser engraving of the brand logo on the body.
▪ Function customization: Adjustment of channel modes (e.g., adding exclusive light control channels), adaptation of light control protocols (e.g., compatibility with the customer's own central control system), and special scenario functions (e.g., increasing the waterproof level of outdoor models to IP65).
▪ Parameter customization: Extended stroke of elevating lights (default 0-5 meters, customizable up to 10 meters), adjustment of the beam angle of conventional lights (e.g., custom 15° narrow beam angle for PAR lights).
