FENG-YI Kinetic Triangle LED Panel — Installation Guide
Clear, step-by-step installation guide for FENG-YI Kinetic Triangle LED light panels. Covers site prep, mounting, power, data connections, programming tips, safety and maintenance, plus professional support from FENG-YI.
Product Information
Introduction
FENG-YI presents a practical installation guide for Kinetic Triangle LED light panels. Designed for performance spaces, retail, TV and cultural events, these panels combine reliable hardware and flexible programming. This guide explains easy-to-follow steps for a safe, stable installation and highlights FENG-YI’s global support services.
Before You Start
Site and Tools
Check site weight limits, access routes and ceiling structure. Prepare basic tools: drill, level, torque wrench, cable ties, multimeter and safety gear. Confirm you have the panel layout, power plan and control protocol (e.g., Madrix).
Inspection
Unpack panels and inspect for damage. Verify serial numbers and component list. Test each panel with a bench power source to confirm LEDs light up before mounting.
Mounting and Mechanical Setup
Mount Points
Use the specified brackets and fixtures supplied by FENG-YI. Mark and drill mounting points according to the panel template. Ensure all fasteners are tightened to spec and use safety cables for overhead installations.
Alignment
Level and align panels to maintain the triangular geometry. Small gaps can affect final visuals, so adjust brackets until edges meet uniformly.
Electrical and Data Connections
Power
Connect power following the panel’s rated voltage and current. Use dedicated circuits and surge protection. Verify grounding is solid to prevent interference.
Data and Control
Connect DMX or Ethernet data cables per the layout. For Madrix or compatible controllers, follow the recommended network topology. Label cables clearly for future troubleshooting.
Programming and Testing
Run a step-by-step power-up with one panel at a time. Use test patterns to confirm color, brightness and response. FENG-YI offers on-site programming and remote guidance to finalize motion and lighting effects.
Maintenance and Safety
Schedule regular inspections for fittings, cables and connectors. Clean panels with a soft cloth and avoid harsh chemicals. Follow local electrical codes and keep firmware up to date.
Support and Warranty
FENG-YI, established in 2011, provides global technical support, onsite installation, programming and remote assistance. With a professional design team and experienced technicians, FENG-YI ensures reliable performance and prompt service for every kinetic lighting project.
Certificate display
A Multifunctional Display Light
A DMX Multiplex Signal Amplifier
Stage-Lighting-Equipment-Compliance-Certificate
Frequently Asked Questions
What is the delivery timeline?
Standard configurations: approx. 4–8 weeks; custom projects depend on scale and logistics. Expedited options and rental alternatives available.
Can accessories (e.g., power cords, DMX signal cables, lamp beads) be purchased separately after the lights have been used for many years?
Separate purchase of accessories is supported. Common accessories (power cords, signal cables, standard lamp beads) are in stock and will be shipped within 1-3 days after ordering. Special accessories (e.g., hydraulic pumps for elevating lights, XY-axis motors for moving head lights) need to be reserved 3-5 days in advance. The after-sales team can provide accessory installation guidance (e.g., sending installation videos).
Is there a regional protection policy to avoid competition among multiple wholesalers in the same region?
For prefecture-level cities and above, an "exclusive wholesale cooperation" policy is implemented: If there is already a cooperative wholesaler in a region (with an annual purchase amount of ≥ 300,000 RMB), no second wholesaler of the same type will be developed. For county-level regions, 2-3 wholesalers can be developed based on market demand, but clear sales scopes must be divided (e.g., by town) to avoid vicious competition.
Can on-site installation services be provided? How is the installation fee calculated?
On-site installation services are supported, and the fee is calculated based on the installation difficulty and region:
▪ Regular installation (e.g., bar PAR lights, front lights in small studios): 50-100 RMB/unit in prefecture-level cities and above, 80-150 RMB/unit in county-level regions.
▪ Large-scale installation (e.g., elevating lights in stadiums, moving head light groups for music festivals): Quoted based on the overall project (including travel expenses of installers and tool usage fees). Specific details require providing the installation site floor plan and the number of lights, and the engineering team will formulate a plan before quoting.
